Drone Window Facade Washing Aerial Cleaning System For DJI M350

SKU: RT-AP3 Category:

The DJI M350 high-pressure window washing aerial cleaning system is compatible with drones and has a payload of 3-10kg (6- 22 lbs). It offers an efficient and versatile high-pressure aerial cleaning solution for various scenarios, including building exteriors, facades, windows, solar panels, insulator strings, wind turbine towers, and tall structures.

Features:

  1. supports Tethered Water supply operations, and enables long-duration and continuous operation.
  2. Max. 30 MPa High-pressure Pump, Quickly cleans up hard-to-remove stains.
  3. 800㎡/h quick cleaning, Utilizing a pliable gimbal, the operation rod can be adjusted vertically within a +20~ -40° range, enabling quick cleaning while hovering, covering an area of 800㎡(8611 ft²) per hour.
  4. 120M (393ft)  operating altitude, supports up to 393ft with potential for further expansion.
  5. Hover spray, Adjustable spray from +20 to -40° for hard-to-reach surfaces like undersides and tops.
  6. Quick Installation, Compact design for easy transport and setup, slide-in interface for 1-minute deployment.
  7. seamless Flight Control integration, Fully integrated with a flight system for a single operator to control both navigation and spraying tasks.
  8. For DJI M300/M350, DJI Pilot operates and controls.
  9. Modular Nozzles, Adapts to various tasks with the best-suited nozzle, meeting the needs of indifferent scenarios.
  10. Multi-angle coverage for complex surfaces, Easily cleans bottom and top surfaces through adjustable operation rod.
  11. Fits 3-10kg (6-22lb) Payload Drones, Compact and lightweight design allows navigation and operation through narrow spaces.
  12. Replacing Manual, High-altitude operation Remote operation eliminates risks associated with manual high-altitude tasks.
  13. Adaptive Balance Pliable gimbal can adaptively eliminate sway caused by lateral operations andeffectively counteractflight interferencefrom spray recoil, ensuring operational safety.
  14. Laser Real-time Distance Detection, The detection module displays the real-time operational distance for stable and optimal spraying, with an effective range of up to 3 meters (9.8 ft)

Specs

Specifications Details
Dimensions 936 x 146 x 192 mm / 37 x 6 x 8 inch
Weight of P3 Device 1.3 kg / 2.86 lbs
Max Length of Hose 120M (393 ft)
Water Pump Spraying Pressure Max 30 MPa
Number of Joint 1
Joint Rotation Range +20~-40 Vertical
Time for Installation 1 min
Drones Compatible DJI M300/350
Protection IP55
Adaptive Balance Yes
Supported Liquid Water, acid/alkaline detergent
Wind Resistance 6M/s
Speed 10M/s
Operating Temperature 0~50℃ / 0~122°F
Max Operating Height 120m / 393 ft
Max Cleaning Area per Flight 800㎡ / 8611 ft²
Operating Time per Flight 20 min
Number of Flights for 1000㎡ 5
Operating Time for 1000㎡ 2h
Power for 1000㎡ 1 kWh
Water for 1000㎡ 2T

Weight 1.3 kg
Dimensions 93 × 16 × 19 cm
