GL60 Plus Spotlight Searchlight for DJI M300 drone

SKU: GL60 Plus Category:

GL60 Plus Spotlight Searchlight for DJI M300 drone, it is a DJI PSDK M300 drone spotlight, 120W high power, super brightness up to 13400LM, max lighting area to 1225m², 3-axis stabilization gimbal, synchronized with the rotation angle of DJI H20 series cameras, quick installation and deployment can meet the needs of night operations such as night law enforcement surveillance, warning drive away, orientation indication, power line patrol, search and rescue, etc.


  • High power and super brightness,  Compared with the previous generation searchlights GL60 and GL60 Zoom, the performance of GL60 plus has been greatly improved
  • DJI Payload SDK, control via DJI Pilot.
  • Sync with H20 camera.
  • Imaging optical technology, 4 sets of optical lens groups, 1 group of 4 lenses, 15° beam angle,
  • IP55 waterproof and dustproof, new die-casting heat dissipation process.


Product Model GL60 Plus Spotlight
Powered By DJI Skyport V2.0
Weight 750g
Size 126*131*167mm
FOV 15°
Voltage PSDK 17V+OSDK 24V PSDK 17V
Led Power 120W 60W
Luminous flux 13400lm±3% 8000lm±3%
LM effect 111.67lm/W 133.33lm/W
Drone Flight  Height 50M 100M 150M 50M 100M 150M
Lighjting Spot diameter 13.2m 26.4m 39.5m 13.2m 26.4m 39.5m
Lighting area 136m² 544m² 1225m² 136m² 544m² 1225m²
Central illuminance 85Lux 24Lux 11Lux 45Lux 12Lux 6Lux
Function mode Lighting
gimbal angle adjustment
bright adjustment
Gimbal rotation range Pitch horizontal
 -110°~+30° ±200°
Working temperature  -20°C~+50°C

Weight 3 kg
Dimensions 12 × 12 × 23 cm
